WWP-BG350

High speed automatic vertical bagging machine

This machine is mainly used to package semi-finished products, such as bottles, cans, and boxes. When these bottles, cans, and boxes are not filled with products, they need to be covered with a layer of film to protect the appearance of the product. Avoid damaging the appearance of bottles, cans, and boxes during shipping. This machine uses a moving knife. The moving knife is installed vertically and 90 degrees to the conveying surface. When it senses bottles, cans, and boxes, it cuts the bags while moving to increase the packaging speed.

| Item | Specification |
|---|---|
| Model | WWP-BG350 |
| Speed | 0–50 pcs/min (depending on product size) |
| Sealing & Cutting Size | Horizontal knife 350 mm |
| Net Weight | 600 kg |
| Power | 5 kW |
| Power Supply | 380V, 50/60Hz |
| Max Current | 10 A |
| Air Pressure | 6–8 kg/cm² |
| Machine Dimension | L2500 × W1000 × H1800 mm |
| Table Height | 830 mm |

## Specifications

1. The heating system adopts stainless steel heating tubes, providing a long service life.

2. Equipped with an anti-stick high-temperature sealing knife. The integrated design ensures stronger and more attractive sealing. The knife surface is coated with Teflon non-stick material to prevent film adhesion.

3. The sealing knife temperature is controlled by a Japanese **OMRON digital temperature controller** with an imported heat-sensitive sensor. The temperature can be adjusted from 0–300°C.

4. The sealing knife protection system adopts German **SICK** technology to effectively prevent incorrect sealing and protect packaging products.

5. The cylinder adopts Taiwan **SHAKO** or **AirTAC** cylinders to ensure firm and accurate sealing.

6. The **Uda servo sealing and cutting drive system** ensures stable and reliable sealing performance.

7. The film pulling system adopts a **Uda stepper motor** to ensure accurate and stable film feeding.

8. The conveyor motor adopts a planetary integrated servo motor, ensuring high-speed and stable conveying.

9. The traverse motor adopts a **Uda servo motor** to ensure high-speed and smooth product transportation.

10. The material dividing and anti-returning systems are controlled by **INVT inverters** with medium-sized motors, ensuring high-speed and stable conveying.

11. The film feeding motor adopts a medium-sized motor to ensure high-speed and stable film transportation.

12. The film feeding induction and detection system adopts American **Banner photoelectric sensors** for accurate and sensitive product detection and stopping control.

13. The material dividing detection system adopts German **SICK photoelectric sensors** for precise and sensitive product detection and stopping control.

14. Equipped with multiple air exhaust punches to quickly remove air inside the bag during shrinking.

15. The surface treatment uses anti-corrosion structural materials with plastic spraying or nickel plating processes.

16. Mechanical parts are made of carbon steel with plastic coating. Key components use stainless steel plates and aluminum profiles to ensure a strong and durable structure.
